Precast concrete detailing software for modeling prefabricated buildings in Revit®

Precast Concrete software for Revit streamlines your 3D design process by automating the modeling, detailing, and documentation stages. Efficiently model floor slabs, wall panels, beams, and columns. Insert connection details by the batch-load and place reinforcement. By leveraging BIM, all your shop drawings are automatically generated from the 3D model. And if any changes are made to the project, enjoy the benefits of running full-project, real-time updates on the Revit platform. The end result? Quality production and accurate assembly on site.

  • Model precast concrete walls and floors with easy split, update, and modify options.
  • Automatically insert connection details throughout your BIM model according to your predefined rules. (That includes plates, lifting bolts and inserts, steel bar, reveals, cuts, grout tubes, loop connections, etc.)
  • Make element sections and views with automatic dimensions, and generate bills of materials and shop tickets for quality fabrication and accurate on-site assembly.
  • Manage changes in your project and benefit from dynamic updating of assemblies.

Compatible with Autodesk® Revit® 2021, 2020, 2019, 2018


Autodesk AEC Industry Partner for BIM solution Precast Concrete | AGACAD


Precast Concrete featured by Autodesk

AGACAD becomes one of Autodesk’s first AEC Industry Partners

PRESS RELEASE – Vilnius, 9 October 2018



What does the workflow look like?

CREATE PRECAST ELEMENTS – INSERT CONNECTIONS – PLACE REBAR – SORT ELEMENTS – GENERATE SHOP DRAWINGS

Going to build a modular building: school, library, parking garage, or dorm? Perhaps an apartment building or a high-rise? Maybe the county jail? Whether you’re designing a commercial or residential construction project, precast concrete can get the job done fast and stand the test of time. And our Precast Concrete Revit-based software will help boost your profits and keep costs down by saving time, eliminating or automating lengthy tasks (shop tickets, anyone?), and speeding up the workflow. It also ensures that best practices are followed because we went ahead and built them right into the software for any design standard. And what's more, we continually implement feedback that comes in from our expert users.

BIM model of precast concrete parking garage using AGACAD Precast Design design software for Revit

Do you need to model concrete reinforcing steel? No problem. Our software works for reinforced precast concrete. If it’s prefabricated concrete slabs or walls, columns, or beams that you’re modeling, our Revit application will streamline your process.

reinforced solid wall using Revit addon for precast concrete walls | Wall Reinforcement | AGACAD

Watch our videos below to get an idea of how you can model structural elements, place rebar, auto-format dimensions in your shop tickets, export fabrication information to CAM (computer aided manufacturing), or model a parking garage in Revit using our Precast Concrete design software. For structural engineers, civil engineers, BIM managers, precast detailers, designers, and manufacturers alike.

Basics of Modeling & Documentation of Precast Concrete in Revit [SNEAKPEEK]
Precast Concrete Design, BIM, and Revit [WEBINAR]


Modeling a Precast Concrete Parking Garage in Revit [WEBINAR]
Modeling Precast Concrete Slabs in Revit [SNEAKPEEK]

Modeling Precast Concrete Walls in Revit [SNEAKPEEK]
Modeling Precast Concrete Columns & Beams in Revit [SNEAKPEEK]
Placing Reinforcement in Precast Concrete w/ Dynamo + BIM modeling in Revit, CAM & shop drawings [WEBINAR]
Automated Wall Reinforcement in Revit [WEBINAR]
Inserting Dimensions Automatically in Shop Drawings in Revit [WEBINAR]
Automated Beam Reinforcement in Revit [WEBINAR]


The table below shows which parts of the precast concrete building design process can be accomplished using Revit and which parts pertain to our Precast Concrete design software.

Precast Element
(or Process)
Modeling
Main
Elements
Inserting Details, Connections, Cuts, etc. Numbering
& Sorting
Documentation (Schedules/ Shop Tickets/ Shop Drawings/ Material Takeoffs)
Foundations Revit Smart Connections Sort Mark Smart Assemblies
Precast columns Revit Smart Connections
Sort Mark Smart Assemblies
Precast beams (rectangular, I, L, T, or inverted T beams, I-girders) Revit Smart Connections
Sort Mark Smart Assemblies
Double Tee slabs Floor Panel Layout/ Floor+C / Revit
Smart Connections Sort Mark Smart Assemblies
Hollow Core slabs (voided slab or concrete plank) Floor Panel Layout/ Floor+C/ Revit
Smart Connections
Sort Mark Smart Assemblies
Massive slabs Floor Panel Layout/ Floor+C/ Revit
Smart Connections
Sort Mark Smart Assemblies
Filigran slabs Floor Panel Layout/ Floor+C/ Revit
Smart Connections
Sort Mark Smart Assemblies
Massive walls Smart Walls/ Revit Smart Connections Sort Mark Smart Assemblies
Sandwich walls Smart Walls/ Revit Smart Connections Sort Mark Smart Assemblies
Architectural walls Smart Walls/ Revit Smart Connections
Sort Mark Smart Assemblies
Spandrels Smart Walls/ Revit Smart Connections
Sort Mark Smart Assemblies
Architectural sills, banding, lintels, coping, modular veneer Smart Walls/ Revit Smart Connections
Sort Mark Smart Assemblies
Socle panels Smart Walls/ Revit Smart Connections
Sort Mark Smart Assemblies
Stairs Revit Revit Sort Mark Smart Assemblies
Stair landings Revit Revit Sort Mark Smart Assemblies
Reinforcement (Rebar/ Steel bar) Wall Reinforcement/ Beam Reinforcement/ Column Reinforcement/ Revit
Sort Mark Smart Assemblies

connection details in a BIM model of precast concrete | AGACAD Precast Concrete design software for Revit



Our Precast Concrete design software comprises powerful features.

Floor Panel Layout




REVIT TOOL FOR DIVIDING A FLOOR INTO PREFABRICATED FLOOR PANELS

  • Automatically divide an architectural floor into regions by using supports, edges, and openings
  • Divide and create separate slabs from selected floor or floor faces by a predefined spacing and layout method
  • Create individual floor segments – solid (massive) slabs, hollow core slabs (voided slabs, hollow core plank, concrete plank) roof slabs, steel-reinforced slabs – according to panel layout
  • Update panels accordingly if the architect changes the floor design
  • Control, align, modify, or split panels as needed

Floor+C


REVIT EXTENSION FOR MAKING SLABS WITH STRUCTURAL FRAMING MEMBERS

  • Lay out structural framing elements based on rules
  • Define rules in the framing configurations
  • Automatically create warped Double Tee (DT) slabs
  • Make layouts of any section of structural system framing elements — hollow core slabs, steel decking for composite slabs, and more
  • Especially useful for designing parking garages with warped DT slabs or when structural framing family has camber

Smart Walls


REVIT ADDON FOR MANAGING WALLS & JOINS

  • Manage information of all wall systems in your project (load-bearing and non-bearing walls)
  • Export filtered, grouped, or selected information (wall parameters) to Excel
  • Decompose wall layers into separate wall types according to user's predefined configuration
  • Fully control joins and gap distances between walls
  • Calculate center of gravity
  • Add additional information about real wall orientation, elevation, or coordinates
  • Split walls at exact locations by using grid lines, openings, or other walls
  • Split walls automatically by predefined panel size

Beam Reinforcement

REVIT TOOL FOR PLACING REBAR IN BEAMS EFFICIENTLY

  • Create, update, and modify reinforcement for rectangular, L, and IT beams
  • Extend rebar outside beam if needed
  • Tie selected main rebar with stirrups of various shapes per your configurations
  • Place couplers

Wall Reinforcement


REVIT PLUGIN FOR PLACING REBAR IN WALLS EFFICIENTLY

  • Create, update, and modify reinforcement for solid walls, double walls, and sandwich walls
  • Recognizes wall shape and distributes main mesh and additional reinforcement for wall perimeter and openings
  • Vertical, horizontal, diagonal, and U-shaped bars and edge reinforcement

Column Reinforcement


REVIT TOOL FOR PLACING REBAR IN COLUMNS EFFICIENTLY

  • Create, update, and modify reinforcement for columns
  • Place main reinforcement, stirrups, and corbel rebar based on rules you set in the configurations
  • Tracks corbel position and places rebar accordingly

Smart Connections


REVIT APPLICATION FOR AUTOMATED LOD 400 MODELING IN REVIT

Insert grout tubes, cast-in steel plates, anchor bolts, lifting bolts, lifting anchors, lifting eyes, footing connectors, cuts, and reveals on the surface of any host element, be it a beam, column, wall, foundation, floor, Part, or Generic model.

  • Rule-based distribution of details and voids on any element surfaces
  • Simple insertion of point-based and line-based details
  • Host-element data can be read and used to modify detail families automatically
  • Easily rotate/flip details in configuration window to get desired result
  • Check whether host element has enough solid body for detail to be inserted
  • Insert details according to gravity point
  • Insert details at intersection points of other Revit elements
  • Quick modification and updating of inserted details
  • Automatically insert details based on a defined configuration name
  • Smart Assemblies, used for workshop drawings, recognizes changes made by Smart Details/ Smart Connections

Sort Mark


REVIT ADDIN FOR FLEXIBLE ELEMENT & GRID RENUMBERING

Sort and mark precast elements based on their volume, location, ID, length or any other available parameters.

  • Powerful and flexible functions let you easily renumber any Revit elements (beams, columns, foundations, walls, connections, etc.) in a number of ways
  • Automatic recalculation of shared X, Y, Z coordinates
  • Create new shared parameters and benefit from many other handy functions
  • Save numbering settings under a separate name
  • Sort elements in ascending or descending order

Smart Assemblies


REVIT APP FOR AUTO-GENERATING SHOP TICKETS WITH CORRESPONDING VIEWS & DIMENSIONS

Create views of foundations, walls, beams, columns, and floors with dimensions and place them where they should go on sheets — all automatically.

  • Automatically add all hosted elements to an assembly
  • Use various templates to automatically create views
  • Auto-generate schedules based on schedule templates
  • Rule-based creation of dimensions with notes in selected views
  • Place views on sheets automatically based on a sheet template
  • Create multiple assemblies with defined configurations in a single click
  • Calculate assembly mass
  • Easily check, update, edit, and change dimensioning configurations of selected assemblies
  • Update assemblies based on project changes
  • Select/find/isolate primary and secondary assemblies
  • Find changes in assemblies due to new hosted details
  • Insert details/cuts on all assemblies of the same type with one click
